opus

Opus is an ultramodern 12-channel electrocardiograph designed for the most demanding users

opus
opus
01

Modern ECG

Opus 1 is an ultra-modern 12-channel electrocardiograph designed for the most demanding users. The 10'' high-resolution touch screen allows for simultaneous monitoring of all 12 leads and the high-quality printouts on 210 mm wide paper, provide a perfect diagnostic image. It has a unique feature of changing sample levels up to 16 000 Hz guaranteeing exceptional clinical precision. It is equipped with a high-capacity hard disk drive, from which it is possible to wirelessly export test results (tests) in many formats (e.g. PDF, XML, SCP) to an HIS (Hospital Information System) server or CardioCLOUD (cloud storage). The additional space designed for a backup roll of paper allows for continuous testing. Opus 1, as a standard, provides the possibility of using the consumables ordering center and online technical support. A lifetime warranty is available in the Premium subscription package. The device is available in 3 color options.

Opus
technical parameters
screen
LCD IPS 10,1”,
LCD IPS 10,1”,
resolution
1280x800 px
1280x800 px
Internal memory
100 000 examinations
100 000 examinations
Power supply
100V to 250V , frequency 50/60Hz
100V to 250V , frequency 50/60Hz
External printer
wireless
wireless
Sampling
Up to 16 000 Hz
Up to 16 000 Hz
EXPORT/IMPORT
HL7, DICOM, Cloud, PDF, XML, SCP
HL7, DICOM, Cloud, PDF, XML, SCP
INTERFFACE
WI-FI/LAN, BLUETOOTH, HDMI FULL HD, USBx3, SD card, network printers
WI-FI/LAN, BLUETOOTH, HDMI FULL HD, USBx3, SD card, network printers
Battery Capacity
Up to 8h
Up to 8h
Network interference filter
50/60 Hz
50/60 Hz
Muscle noice filter
25, 35, 45 Hz
25, 35, 45 Hz
Isoelectric line filter
0.15 to 1.5 Hz
0.15 to 1.5 Hz
features and benefits
Order Point
String Premium
Online assistant
Data protection
CardioCLOUD
02
Interface
CHOICE OF FILTERS
DATABASE
PATIENT PROFILE
PRINT SETTINGS
  • CHOICE OF FILTERS
  • DATABASE
  • PATIENT PROFILE
  • PRINT SETTINGS
04
We work with
specialized hospitals
clinics
clinics
Doctors offices
read about STRING
Are you interested in buying?
Contact us, get to know our offer.
